| Product Code: | HR0534 |
| Availability: | 9751 |
Feature:
Profile Dimensions: 260x240x220mm
engraving area: 160x100x30mm
Screw: Professional T8 screw, lead 4mm, double copper nuts eliminating backlash
Stepper motor: new 42 stepper motor. reliable quality
Voltage: 12V, phase current 1.3A, 2.1 European phase resistance, torque 0.25N.m
Spindle: 775 spindle motor (12-36V) 24V: 7000r / min, 36V: 9000r / min
Laser head: See Package
Power: stepper motor power: 12V 3A adapter
Spindle motor power: 24V 5A adapter
Table: 20100 profile (table size: 180x100mm)
Frame: 2020 Profiles
Gray Material: Plastic
Usage : can be engraved plastic, wood, acrylic, pvc, pcb, wood or the like material.
Summary:
Plastic body with a profile, small size, light weight, USB interface, GRBL control systems, learn to use the preferred entry. Either by inscribing, and can be carved with lasers.
The following software:
Control Software: GrblController
Toolpath creation software: Artcam2008
PCB processing software: Coppercam
Description: Some components and core components have been assembled, simply hand assembled according to the installation instructions, you can use the rack .
